Large Stainless Steel 5 Ton Cube Ice Machine Energy Saving Directly Cooling

Basic Information
Place of Origin: China
Brand Name: CBFI
Certification: ISO,CE
Model Number: CV5000
Minimum Order Quantity: 1 set
Price: $100,000
Packaging Details: Wooden Case
Delivery Time: 30 days after payment
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 30 sets per month
Contact Now
Detail Information
Compressor: Germany Bitzer Cooling Way: Water Cooling
Ice Size: 22*22*22mm Or 29*29*22mm Or 38*38*22mm Evaporator: Nickeled Cube Ice Mold
Material: 304 Stainless Steel For All Frame Daily Capacity: 5 Tons
Refrigerant: R404a Or R22

Product Description

Large Stainless Steel Directly Cooling Easy Operating Energy Saving 5 Ton Cube Ice Machine





5 Ton electricity saving Ice Cube Machine


1. Capacity: 5 ton per 24 hours

2. Power Consumption: 85kw.h

3. Power Supply: 380V/50Hz/3P (Can be changed)

4. Cooling way: water cooling or air cooling



Large Stainless Steel 5 Ton Cube Ice Machine Energy Saving Directly Cooling
                                                         5 ton cube ice machine



Feature of 5 Ton electricity saving Ice Cube Machine

 1Low power consumption : 80~85 kw.h/ton. Greatly saves your cost.

2. Foot switch : Ice outlet controlled by foot swticth, free your hand to packing the ice, avoid the second human polluction.

3. Easy to operate: We adopt PLC system design, one key to start or stop the machine, touch screen control .

4. Ice Molds: Nickeled Copper Ice Mold, which can resistant to 70% following concentrated nitric acid erosion.When washing ice machine,the low concentration of acetic acid will clean not thorough,high concentrations will eroded ice mold. And our ice mold can avoid this problem.

5. Earthquake proof : Fixed the copper tube and Protect and shockproof coper tube. The shockproof size is fixed in front of the copper tubes and evaporator welds,which can avoid being damaged during transport or use.

6. Convenient to install: The machine unit had been tested in our factory for 24 hours continjously. So, the machine unit can start once electric power has been connected and water supply has been connected.




Product Model



Model
Ice Making
Capacity
Rated
Power



Circulating Water
Pump Power
Cooling Water Pump Capacity
Cooling Fan Capacity
Dimension
Weight of Machine
No.
Ton/24h
kw
kw
kw
kw
W*H*L(mm)
KG
CV1000
1.0
3.69
0.37
1.5
0.37
1800*1000*1600
800
CV2000
2.0
7.11
0.37
1.5
0.55
1630*1600*1686
1000
CV3000
3.0
9.68
0.37
2.2
0.75
1980*1630*1840
1200
CV5000
5.0
18.84
0.55
2.2
1.5
2890*1780*1840
1600
CV8000
8.0
28.52
1.1
4
1.5
4820*1780*2000
2500
CV10000
10.0
37.68
1.1
4
1.5
5730*1780*2000
3000
CV15000
15.0
52.41
1.65
5.5
2.2
8620*1780*2000
4500
CV20000
20.0
75.36
2.2
8
3
11460*1780*2100
6000







5 ton daily capacity cube ice machine
