Product Details:
|
| Product Name: | Flake Ice Machine | Cooling Method: | Air Cooled/Water Cooled |
|---|---|---|---|
| Refrigerant: | R507/R404A | Ice Shape: | Flake |
| Control System: | PLC Control | Ice Storage Capacity: | Customized |
| Compressor Brand: | Copeland, Hanbell, Bitzer, Etc. | Application Fields: | Food Processing |
Flake Ice Making Machine With Rake System Screw Transportation Flake Ice For Fish Port
In recent years, the fishing industry has been developing rapidly, and the demand for high-quality flake ice has also increased. As a result, industrial ice makers have developed various types of ice machines to meet the needs of the fishing industry. Among them, the rake type flake ice machine equipped with a spiral conveyor has become the preferred choice in most fishing ports due to its many advantages and features.
Firstly, the spiral conveyor of rake type flake ice machine can transport flake ice to different locations quickly and efficiently. The spiral conveyor can adjust the delivery speed according to the actual needs of the production line, which can reduce the waiting time of flake ice and improve production efficiency.
Secondly, the spiral conveyor can transport different shapes and sizes of plate ice and can handle them with high accuracy. It has an automatic protection system that can detect and remove any impurities or damaged ice blocks in the production line, which can prevent blockages and improve the quality of flake ice.
Thirdly, the spiral conveyor is easy to operate and maintain. It requires only a small amount of maintenance work, and it is more durable and reliable than other types of conveyor belts. The spiral conveyor can be easily cleaned, which can prevent cross-contamination and ensure the hygiene of the production line.
Besides, the use of flake ice in fishing ports can also have a significant impact on fish preservation. Flake ice has a low temperature and high heat exchange rate, which can quickly cool down and freeze fish, preventing them from deteriorating quickly and reducing the loss of nutritional value. The use of flake ice can ensure that the fish are kept fresh and of high quality during transportation and storage.
|
Flake Ice Machine Parameters
|
|||||||
|
Model
|
Daily Output (T/24h)
|
Cooling method
|
Compressor Power
|
Fan Power for Cooling Tower
|
Cooling Pump Power
|
Unit Size
(L*W*H mm)
|
Unit N.W. (KG)
|
|
BF 1000
|
1
|
Air
|
7.44 kw
|
--
|
--
|
1320*900*900
|
210
|
|
BF 2000
|
2
|
Air
|
10 kw
|
--
|
--
|
1750*1100*1050
|
360
|
|
BF 3000
|
3
|
Water
|
8.45 kw
|
0.37 kw
|
1.5 kw
|
1500**1250*1260
|
1000
|
|
BF 5000
|
5
|
Water
|
13.49 kw
|
0.75 kw
|
2.2 kw
|
1900*1500*1470
|
1100
|
|
BF 6000
|
6
|
Water
|
19.94 kw
|
0.75 kw
|
2.2 kw
|
1900*1500*1470
|
1100
|
|
BF 8000
|
8
|
Water
|
24.2 kw
|
1.5 kw
|
2.2 kw
|
2400*1900*1860
|
1300
|
|
BF 10000
|
10
|
Water
|
33.8 kw
|
1.5 kw
|
4 kw
|
2500*2000*1860
|
1500
|
|
BF 15000
|
15
|
Water
|
44.5 kw
|
1.5 kw
|
4 kw
|
3350*2150*1960
|
3200
|
|
BF 20000
|
20
|
Water
|
64 kw
|
1.5 kw
|
5.5 kw
|
3400*2220*2230
|
4200
|
|
BF 25000
|
25
|
Water
|
76.5 kw
|
2.2 kw
|
5.5 kw
|
3700*2250*2510
|
4600
|
|
BF 30000
|
30
|
Water
|
93.7 kw
|
2.2 kw
|
7.5 kw
|
4700*2250*2520
|
5000
|
|
BF 40000
|
40
|
Water
|
118 kw
|
2.2 kw
|
7.5 kw
|
5000*2300*2700
|
7500
|
|
1. Compressor brand: Bizter / Hanbell; Refrigerant: R507/R404R.* Power supply: voltage 380 V/3P/50Hz (For non-standard voltage, unit configuration needs to be calculated separately)
2. Operating conditions: T (water supply):20℃, T (ambient): 32℃, T (condensing): 38℃, T (evaporating): -20℃. 3. Note: The actual ice production varies due to the influence of water supply temperature and ambient temperature. 4. The final interpretation of the above mentioned parameters is in Icesource, there will be no further notice, if there is any technical change. |
|||||||
