Product Details:
|
Model No.: | 1000kg 2000kg 3000kg 5000kg 10000kg 20000kg Per Day | Brand: | CBFI |
---|---|---|---|
Compressor: | Bock Copeland | Cube Ice Size: | 22mm * 22mm * 22mm Or 29mm * 29mm * 22mm |
Machine Main Fram Material: | Stainless Steel 304 | Refrigerant: | R507 Or R404a |
Loading Port: | Guangzhou Port | Cooling Way: | Water Cooled Or Air Cooled |
High Light: | 5000kg/Day Ice Cube Machine,Copeland Ice Cube Machine |
Commercial Edible High quality Cube Ice Making Machine from China with Cube Ice 29mm*29mm*22mm
Commercial Ice Cube Maker Machine 1000kg 2000kg 3000kg 5000kg Per Day
1, the capacity 100% reached is under run condition far above the international standard(water temp:16 ℃,ambient temp:21℃). our standard is :water temp:21 ℃,ambient temp:25 ℃.
2, PLC control, from the ice making to ice falling, can be accomplished automatically
3, semi-automatic ice packing system, save you time and labor
4, stainnessstell 304, ensure you both the sanitary and longer service life to be more than 10 years.
5, compact design, take your little place.
6, fast harvest, only 20 to 23 min , can harvest the delicious ice cubes
7, thickness adjusted easily , through the water supply box, the thickness can be adjust along the float ball level.
Ice Information | Ice shape | Cube Ice | ||
Ice Size (mm) |
Freezing time (min) |
Ice output shift per day |
Weight of per hour (kg) |
|
22*22*22 | 16 ~ 18 | 84 | 207 | |
29*29*22 | 20 ~ 23 | 63 | 207 | |
Ice Density | 500~550kg/m3 | |||
Ice Mold Material | Nickeled Copper | |||
Ice Mold Quantity | 18 pieces | |||
Ice Storage Bin Capacity | 400 kg |
Compressor | Brand Name | |
Type | Semi-Hermetic Piston type | |
Product Model | 6HE-28 | |
Power | 21kw | |
Refrigerating Capacity | 60.2 kw |
Cooling Tower | Brand Name | CBFI |
Size | Φ1615*1890 mm | |
Power of Cooling Water Pump | 2.2 kw | |
Power of Cooling Fan | 0.55 kw | |
Cooling Water Consumption | 0.05 m3/h |
Ice making water Circulating pump | Brand Name | Nanfang |
Power | 0.55 kw |
Ice Outlet Motor | Brand Name | Nord |
Power | 0.75 kw |
1. Water saving: water can be totally circulating.
1Ton water can make 1Ton ice for air-cooled ice machines.
1.1Tons’ water can make 1Ton’s ice for water-cooled ice machines.
2. Power consumption saving design:
CV5000 ice cube machine: 70~85KW*H to make 1Ton ice
Small ice cube maker: 140~150KW*H to make 1Ton ice.
2 sets of 3 tons cube ice machine in Bahrain.
4. Installation:
1). Installing by the user: we will test and install the machine before shipment, all necessary spare parts, operation manual and CD are provided to guide the installation.
2).Installing by CBFI engineers:
Delivery time | 30 days after the receipt of deposit | |
Machine Size | Machine size | 2890*1780*1840mm |
After Packing | 3100*1820*1900mm | |
Loading Volume (Include the Cooling Tower ) |
12 m3 | |
Shipping Container | About half 20 feet Container | |
Machine Weight | 1600 kg | |
Packing | International standard wooden case for Ice machine. |
