Product Details:
|
| Product Name: | Double Spiral Quick Freezer | Product Material: | 304 Stainless Steel |
|---|---|---|---|
| Cooling Method: | Freon | Production Capacity: | 200kg/h~ 10000kg/h |
| Spiral Cage Diameter: | 1200mm~4550mm | Conveyor Width: | 400~1372mm (16~54 Inches) |
| In And Out Position And Direction: | Customized | Dimension(L*W*H): | 15000mm*2200mm*2400mm, 16300*6300*3800mm |
| High Light: | 10000kg/h Double Spiral Freezer,Double Spiral Freezer For Food Factory |
||
Double Spiral Freezer Quick Freezing Machine for Food Factory Use
In the food processing industry, freshness, quality and consistency are the key factors that determine the success of the product. The traditional methods of storing food items such as refrigeration cannot guarantee the preservation of freshness and the quality of the product.
This is why Spiral Freezer technology is becoming increasingly popular in the food processing industry for freezing and chilling food products quickly and efficiently. Spiral Freezer is a type of freezing equipment that uses a spiral conveyor to move the food product through a refrigerated area. The conveyor moves the product in a circular motion, which ensures that the product receives an even and consistent cold treatment.
The design of a Spiral Freezer consists of a continuous belt that rotates on a spiral track. This belt allows the food product to move through a series of cooling zones, which ultimately freeze or chill the product. The cooling zones consist of high-speed, low-temperature fans that circulate air through the chamber to rapidly cool the food product.
The speed of the conveyor belt can be adjusted to match the processing time required for the food product. This feature ensures that the product is frozen or chilled to the desired temperature, regardless of size or shape.
Spiral Freezers can handle a variety of food products such as meat, seafood, vegetables, fruits, baked goods and more. They are commonly used in bakeries, dairy plants, meat processing facilities and frozen food storage facilities.
The benefits of using a Spiral Freezer are numerous. The conveyor belt design allows for maximum space utilization, making it an ideal solution for facilities with limited floor space. The freezing or chilling process is also faster and more efficient than traditional methods, reducing the risk of product deterioration and extending the shelf life of the product. Due to the decreased processing time, the energy consumption of the Spiral Freezer is less than that of traditional methods. This means that Spiral Freezers can save the facility owner money on electricity costs.
In addition, Spiral Freezers are easy to clean and maintain. The belt design allows for easy access and cleaning of all parts of the machine, reducing the risk of bacterial buildup and contamination. This feature is especially important in the food processing industry, where cleanliness and hygiene are critical.
In conclusion, Spiral Freezers are a valuable asset in the food processing industry. Their speed, efficiency, and ease of use make them a cost-effective solution for freezing or chilling food products. As the demand for fresh, high-quality food products increases, the use of Spiral Freezers is likely to continue to grow.
Spiral quick-freezing equipment consists of three basic systems:
1. Thermal insulation system: a low-temperature space enclosed by polyurethane thermal insulation panels.
2. Heat exchange system: evaporator, fan, air duct system.
3. Transmission system: a transmission system composed of a conveyor belt, a reducer, and a spiral tower.
Features of spiral quick freezing equipment
| No | Features | Interpretation |
|
1 |
Compact structure | The structure in the warehouse is compact, leaving only the necessary air ducts and maintenance access, without wasting space. |
| 2 | Wide range of applications | It can freeze most foods, except those that are too large. |
| 3 | Small footprint | The height and space are used to reduce the length and width, which is very suitable for modern factories where every inch of land is expensive. |
| 4 | High degree of automation | It can be connected to an automatic production line, continuous operation, and no manual intervention is required from food entry to exit. |
| 5 | Large freezing capacity | The form of the spiral structure greatly increases the food placement area, and the production capacity is large. |
| 6 | Non-standard customization is available | The diameter of the cage, the width of the mesh belt, and the number of layers of the mesh belt can be adjusted according to needs to meet different needs. |
Application fields of spiral quick freezing equipment
| No | Industry | Interpretation |
| 1 | Meat | cut meat from livestock, grilled sausage, bacon, fried chicken nuggets, pork chops, small crispy meat, etc. |
| 2 | Aquatic products | fish fillets, shrimp, shellfish, whole fish, whole shrimp, etc. |
| 3 | Rice noodles | Tangyuan, dumplings, noodles, buns, etc. |
| 4 | Hot pot ingredients | all kinds of hot pot ingredients |
| 5 | Baking | pizza, bread, frozen dough, etc. |
| 6 | Ice cream | all kinds of ice cream |
| 7 | Prefabricated dishes | various prefabricated dishes |
