Product Details:
|
| Capacity: | 1-20 Ton/24hours | Ice Cube Shape: | Square |
|---|---|---|---|
| Compressor Brand: | Bizter / Frascold | Refrigerant: | R507/ R404A |
| Name: | Ice Cube Machine | Cooling Method: | Water Cooling / Air Cooling |
| Noise Level: | Low | Ice Cube Size: | 22*22*22 Mm ; 29*29*22 Mm ; 38*38*22 Mm |
| High Light: | Salt Water Cube Ice Machine,Water Cooling Cube Ice Machine |
||
38*38*22 Mm Ice Cube Size Salt Water Cube Ice Machine with Water Cooling Method
The water-cooled square ice maker with dimensions of 38*38*22 mm has become popular in recent times due to its unique advantages. This machine has given users the convenience of producing ice cubes in a relatively faster time compared to traditional ice-making methods.
Advantages of the water-cooled cube ice maker:
1. Faster Ice Making:
The water-cooled cube ice maker has an efficient and fast ice-making process, which can produce up to 25-40 kg of ice per day. This feature makes it perfect for businesses that require a large amount of ice for their daily operations.
2. Easy to Use and Clean:
The water-cooled cube ice maker has a simple operating system that doesn't require any special skills or extensive training to operate. Additionally, the water-cooled system makes it easier to clean the machine, ensuring excellent hygiene and safe ice production.
3. Durable and Reliable:
The water-cooled cube ice maker is made of high-quality materials that guarantee durability and long-lasting use. Its unique design ensures that the ice-making process is not affected by external weather conditions and maintains a consistent supply of ice.
4. Cost-effective and Energy-efficient:
The water-cooled cube ice maker is energy-efficient, making it a cost-effective option when it comes to producing ice. Its water-cooled design ensures that the machine doesn't consume much power, reducing energy costs.
5. Versatile and Multipurpose:
The water-cooled cube ice maker's unique design allows it to produce different sizes of ice cubes, making it perfect for various applications such as cooling beverages, preserving food, and even medical usage.
|
Large capacity cube ice machine for hotels & restaurants paremeters
|
|||||||
|
Model Parameters
|
CV 1000
|
CV 2000
|
CV 3000
|
CV 5000
|
CV 10000
|
CV 20000
|
|
|
Daily output (T/24 h)
|
1
|
2
|
3
|
5
|
10
|
20
|
|
|
Compressor Power
|
4.34 kw
|
7.88 kw
|
10.58 kw
|
21 kw
|
42 kw
|
73.5 kw
|
|
|
Fan Power of Cooling Tower
|
0.18 kw
|
0.37 kw
|
0.56 kw
|
0.75 kw
|
1.5 kw
|
2.2 kw
|
|
|
Cooling Pump Power
|
1.1 kw
|
1.5 kw
|
1.5 kw
|
2.2 kw
|
4 kw
|
5.5 kw
|
|
|
|
L (mm)
|
1800
|
1630
|
1980
|
2890
|
5730
|
7100
|
|
W (mm)
|
1000
|
1600
|
1630
|
1780
|
1780
|
2250
|
|
|
H (mm)
|
1700
|
1706
|
1860
|
1860
|
2130
|
2300
|
|
|
Unit N.W. (kg)
|
800
|
1000
|
1200
|
1600
|
3000
|
5000
|
|
|
1. Size of cube ice: 22*22*22 mm ; 29*29*22 mm ; 38*38*22 mm.
2. Compressor brand: Bizter / Frascold; refrigerant: R507/ R404A;Cooling Method: Water Cooling / Air Cooling.
3. Power Supply: Voltage 380V/3P/50Hz (For non-standard voltage, unit configuration needs to be calculated separately). 4. Operating Conditions: T(water supply):20 ℃, T(ambient):32 ℃, T(condensing): 40 ℃, T(evaporating):-10 ℃. 5. Note: The actual ice production varies due to the influence of the water supply temperature and ambient temperature. 6. The final interpretation of the above mentioned parameter is in Icesource, there will be further notice, if there any technical change. |
|||||||
