Product Details:
|
Compressor: | Germany Brand | Cube Ice Size: | 22mm*22mm*22mm / 29mm*29mm*22mm |
---|---|---|---|
Refrigerant: | R507 / R404a | Material: | Stainless Steel 304 |
Daily Production Capacity: | 1 Ton To 20 Tons | Water: | Pure Clean And Edible Water |
Cooling System: | Water Cooling And Air Cooling | ||
High Light: | Commercial Ice Cube Machine,Ice Cube Maker Machine |
CBFI manufacturer Ice Cube Machine maker stainless steel 304
CBFI Cube Ice Making Machine
Model
|
Ice Making Capacity | Compressor power | Circulating Water Pump Capacity | Cooling Water Pump Capacity | Cooling Fan Capacity | Machine Dimention | Weight of Machine |
No. | Ton/24h | KW | KW | KW | KW | W*H*L | KG |
CV1000 | 1.0 | 3.69 | 0.37 | 1.5 | 0.37 | 1200*1000*1600 | 800 |
CV2000 | 2.0 | 7.11 | 0.37 | 1.5 | 0.55 | 1630*1600*1686 | 1000 |
CV3000 | 3.0 | 9.68 | 0.37 | 2.2 | 0.75 | 1980*1630*1840 | 1200 |
CV5000 | 5.0 | 17.47 | 0.55 | 2.2 | 1.5 | 2890*1780*1840 | 1600 |
CV8000 | 8.0 | 28.52 | 1.1 | 4 | 1.5 | 4820*1780*1840 | 2500 |
CV10000 | 10.0 | 37.68 | 1.1 | 4 | 1.5 | 5730*1780*2000 | 3000 |
CV15000 | 15.0 | 52.41 | 1.65 | 5.5 | 2.2 | 8620*1780*2000 | 4500 |
CV20000 | 20.0 | 75.36 | 2.2 | 8 | 3 | 11460*1780*2100 | 6000 |
After- sales service:
(1) During 2 years after selling, maintenance and parts free of charge.
(2) We can provide 12 months warranty for our machine. During the warranty period, if your machine don’t work, you can send us pictures or video or call us about the fault. We will immediately mail you the solution to solve the problems within 24hours. If the part is broken for nonpersonal reason,we will replace one for free within guarantee period. But if beyond guarantee period, we will charge market price for the new parts.
Note:
1.The above information is on the basis of water-cooled condensing.
2.Size of machine is before installation. It didn’t included the size of cooling tower, which is usually installed outside the room.
3.Machine running condition:
water temperature:23℃,
evaporate temperature:-12℃,
condensing temperature 40℃,
reference valve under 50Hz power supply.
Real production of machine will have a little change according to change of water temperature and ambient temperature.
