30 Tons Tube Ice Machine Siemens PLC Control System Ice Tube Making Machine

Basic Information
Place of Origin: China
Brand Name: CBFI
Certification: CE
Model Number: TV300
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: wooden case or Bubble film
Delivery Time: 30 working days after getting the deposit
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 40 to 50 sets/month
Detail Information
Condition: New Capacity: 30 Tons
Machine Shipping: One 40 Feet Container Refrigerant: R404a/R22
Tube Ice Diameter: 22mm, 28mm, 35mm Control: Siemens PLC System
Cooling System: Water Cooling Sysem Compressor Quantity: 3 Pieces
High Light:

Tube Ice Machine

,

Ice Tube Maker


Product Description

30 Tons Tube Ice Machine Siemens PLC Control System Ice Tube Making Machine



CBFI develops Freon system pipe ice machines (1-30 tons per day) and ammonia system pipe ice machines (10-80 tons per day). Tube ice machine is a mechanical equipment for producing tube ice. It has a hollow or solid cylinder and is widely used for beverage cooling in cafes, bars, restaurants and hotels.

For more than 10 years, we have been committed to the development and manufacturing of cbfi ice machine for many years, we are fully confident that we can provide you with the best tube ice equipment solutions.



Tube Ice Machine Advantages

1. Easy to install and maintain.

2. Food grade SUS304 stainless steel, to ensure that the ice is edible.

3. PLC intelligent control, automatic production, no manual operation.

4. Automatic laser welding, low failure rate.

5. Special water system design, uniform thickness, clear and pure ice.

6. Manual or automatic packing system can be selected.



Ice Tube MachineProduct Features

1. The shape of the ice is a long irregular hollow pipe, with an inner hole diameter of 5mm~15mm.

2. Ice with the smallest contact area and the best melting resistance.

3. Combine water purification technology with tube ice production, and the tube ice produced is edible ice.

4, our company has 22mm, 28mm, 35mm pipe ice machine for customers to choose.



Basic Information of Tube Ice Machine

Model
Daily output
(T/24 h)
CompressorPower
Fan Power for Cooling Tower
Cooling
Pump Power
Unit size (L*W*H mm)
(Integrated Type)
Unit N.W.(kg)
TV 10
1
4.1 kw
0.25 kw
1.1 kw
1100*900*1780
900
TV 20
2
7.44 kw
0.25 kw
1.5 kw
1250*1000*1950
1200
TV 30
3
10 kw
0.55 kw
1.5 kw
1300*1100*2200
1500
TV 50
5
19.9 kw
0.55 kw
2.2 kw
1600*1400*2250
1800
Model
Daily output
(T/24 h)
Compressor
Power
Fan Power for Cooling Tower
Cooling Pump Power
Unit size (L*W*H mm)
(Split type)
Unit N.W.
(kg)
Main Host
Brine Tank
TV 100
10
27.9 kw
1.5 kw
4 kw
1900*1600*1850
1200*1200*3390
3500
TV 100+
10
39.8 kw
1.5 kw
4 kw
2400*1700*2000
1200*1200*3390
3700
TV 150
15
46.4 kw
1.5 kw
5 kw
2700*2000*2200
1500*1200*4250
4250
TV 200
20
55.7 kw
2.2 kw
7.5 kw
2800*2200*2500
1500*1200*4700
6500
TV 300
30
83.6 kw
2.2 kw
7.5 kw
3100*2200*2500
1800*1500*5700
7200
TV 400
40
111.4 kw
2.2 kw
11 kw
3900*2250*2500
2000*1500*6800
8300
TV 500
50
139.3 kw
3.75 kw
15 kw
4500*2250*2500
2200*1800*7200
9500
1. Compressor brand: Bitzer /Franscold ; Refrigerant: R 22/ R 404 A; Cooling Method: water cooling / air cooling.
2.Power supply:voltage 380V/3P/50Hz(for non-standard voltage, unit configuration needs to be calculated separately ).
3.Operating conditions: T (water supply):20℃ , T (ambient): 32℃, T(condensing):40℃, T (evaporating):-12℃.
4.(Note: The actual ice production varies due to the influence of water supply temperature and ambient temperature.)
5.(The final interpretation of the above mentioned parameters is in Icesource, there will be no further notice, if there any
technical change. )



The main reason for the good quality of the ice maker produced by our company is that the compressor, condenser, expansion valve, PLC controller and other important parts are imported. The equipment has good performance and strong anti-interference ability. The external environment has an effect on yield and ice. It has little effect on product quality. A variety of models can meet the needs of different levels of customers.
